Our advancement depends on the superior gear ,superb talents and consistently strengthened technology forces for Trending Products Online Shopping Metal Roof Ridge Cap Roll Forming Machine, On account of superior excellent and aggressive rate , we will be the sector leader, make sure you don’t hesitate to contact us by cellular phone or email, if you’re fascinated in almost any of our items.
Our advancement depends on the superior gear ,superb talents and consistently strengthened technology forces for Metal Roof Ridge Cap Roll Forming Machine, Online Shopping, Roll Forming Machine, Nowadays our merchandise sell all over the domestic and abroad thanks for the regular and new customers support. We present high quality product and competitive price, welcome the regular and new customers cooperate with us!
We can manufacture and design various color steel ridge cap roll forming machines according to customer requirements.
|
Color Steel Ridge Cap roll Forming Machine parameters |
||
| 1 | Decoiler | Manual decoiler or hydraulic decoiler |
| 2 | Raw material thickness | 0.2-0.8mm |
| 3 | Material | As your requirements |
| 4 | Machine dimensions | 7000*800*1500mm |
| 5 | Feeding width | According to your profile |
| 6 | Forming station | 13 to 15 steps |
| 7 | Shaft diameter | 75mm |
| 8 | Shaft material | High-grade 45# steel, heated and quenched |
| 9 | Roller material | High-grade 45# steel, coated with 0.05mm chrome |
| 10 | Forming speed | 10-15m/minute (adjustable) |
| 11 | Transmission type | Chain transmission |
| 12 | Machine frame stand | Welded structural steel, thickness is 18mm |
| 13 | Main motor | 5.5kW from Shanghai, China |
| 14 | Cutting type | Stop hydraulic cutting |
| 15 | Cutting power | 3kW |
| 16 | Cutter material | Cr12 with quenched treatment HRC 58-62 |
| 17 | Cutting length error | ±2mm |
| 18 | Voltage | 380V/50Hz and 3 or according to your requirements |
| 19 | Control system | PLC control system |
| 20 | Size of PLC | 700*1000*300mm |
| 21 | PLC | Delta/Siemens |
Machine details:
Contact details
If you have any needs or questions, please feel free to contact us. We will be waiting for you here 24 hours. Please join us.
