Slitting line machine parameters
|
|
Raw Material (if the material is stainless steel, please tell in advance)
|
1 |
Material: carbon steel and others |
| 2 |
The thickness of the material: 0.4mm-6mm. |
| 3 |
Width: 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm, 60mm |
| 4 |
Input width: 600-1600mm |
|
Hydraulic decoiler with car
|
1 |
The inner size: 450–610mm |
| 2 |
The Max width: 1250mm |
| 3 |
The capacity: 15T 20Ton or more |
|
Flatting and Cutting System
|
1 |
2 shafts for feeding coil, 9 shafts for flatting |
| 2 |
material of flatting: 42CrMo heat treated 50-52. |
| 3 |
hydraulic system. |
| 4 |
2 sets cutting blade |
| 5 |
width of cutting: 600mm–1220mm. |
| 6 |
the material of blade mould: Gr12MoV |
| 7 |
power: 22KW Motor with ZQ650 Reducer |
|
Slitting system
|
1 |
The width range: 200–1300mm |
| 2 |
The precious of the width: ±1mm |
| 3 |
The speed of slitting: 25m/min |
| 4 |
The width can be change. |
| 5 |
Material of the slitting: Cr12MoV. |
| 6 |
Hardness of slitting blade: HRC5860. |
| 7 |
Slitting: 2~3mm 6 lines. |
| 8 |
Quantity of blades: 10 sets. |
| 9 |
Width of side scrap: 3-15mm |
| 10 |
The precious of side scrap: ±0.5mm |
| 11 |
Quantity of side scrap: 2 strips |
| 12 |
Power of the slitting: 37KW, 1000r/min, with ZQ750 Reducer. |
|
Control System
|
1 |
Screen: 3.2inch button screen |
| 2 |
PLC: Delta |
|
Electrical collecting machine with car
|
1 |
Material inner: 550-650mm |
| 2 |
Max Coil width: 1500mm |
| 3 |
Carrying capacity: 5T |
| 4 |
Automatic relax or collect |
| 5 |
Power: 22KW |
