Lowest Price for Aluminum Rolling Shutter Door Forming Machine

Lowest Price for Aluminum Rolling Shutter Door Forming Machine Featured Image
  • Lowest Price for Aluminum Rolling Shutter Door Forming Machine

Short Description:

If buyers need the technician to go abroad , we will arrange the technician, but the buyers should take all the cost , including visa, round trip ticket etc.


Download as PDF

Product Detail

Product Tags

Our business puts emphasis over the administration, the introduction of talented staff, plus the construction of employees building, striving hard to boost the standard and liability consciousness of staff members. Our corporation successfully attained IS9001 Certification and European CE Certification of Lowest Price for Aluminum Rolling Shutter Door Forming Machine, We sincerely welcome you appear to go to us. Hope now we have fantastic cooperation during the upcoming.
Our business puts emphasis over the administration, the introduction of talented staff, plus the construction of employees building, striving hard to boost the standard and liability consciousness of staff members. Our corporation successfully attained IS9001 Certification and European CE Certification of Profile Roof Forming Machine, Profile Roofing Machine, Our staffs are adhering to the “Integrity-based and Interactive Development” spirit, and the tenet of “First-class Quality with Excellent Service”. According to the needs of every customer, we supply customized & personalized services to help customers achieve their goals successfully. Welcome clients from home and abroad to call and inquire!
Machine parameters

Roller shutter door roll forming machine
1 Materials specification Aluminum, galvalume, galvanized and pre-painted galvanized steel.
2 Thickness 0.5mm to 1.0mm.
3 Main motor power 4.5kw.
4 Hydraulic station power 3kw.
5 Feeding width Depends on the model of profile.
6 Yield stress 235Mpa(33KSI) ~ 350Mpa
7 Roll forming speed 12-15 m/minute.
8 Cutting tolerance +/-2.5mm(length≤5000mm); +/-3.0mm(5000mm)
9 Manual uncoiled Max. Capacity: 3000kgs

Manual decoiler
10 Coil inner diameter 508mm/610mm
11 Voltage 380v/50hz/3 phase
12 Numbers of stands 12 stands/stations/pairs for each roll forming system
13 Roller material High grade No.45 forged steel, coated with hard chrome.
14 Active shaft material High grade No.45 carbon wrought steel, which can improve the integrated mechanic feature of the shaft.
15 Electric elements PLC control panel, transducer imported from Mitsubishi of Japan.

Other elements are from famous suppliers of China.
16 Cutter blades Cr12 mold steel with quenched treatment.

 Machine picture display

Roller Shutter Door Roll Forming Machine1 Roller Shutter Door Roll Forming Machine2

Packaging Details：

1. Machine is covered by plastic film.

2. PLC control box, spare parts and other small parts are packed by wooden carton box.

Terms:

1. Delivery: within 60 days after receiving the deposit.

2. Package: export standard package for container.

3. Payment: TT (30% by TT in advance, 70% by TT after inspect the machine before delivery).

Sales service:

1. We provide the technical support for whole life of our machines.

2. If buyers need the technician to go abroad , we will arrange the technician, but the buyers should take all the cost , including visa, round trip ticket etc.
