factory Outlets for s Making Building Material Wall Panel Metal Roofing Corrugated Tile Roll Forming Machine For Sale

Short Description:

Parameters of corrugated automatic roof tile machine: 1)Main motor power: 4kW, 3-phase or as your requests. 2)Hydraulic motor power: 3kW. 3)Hydraulic pressure: 10-12MPa. 4)Voltage: 380V/3-phase/50Hz (or as your requirements).


Product Detail

Product Tags

To create extra value for customers is our enterprise philosophy; buyer growing is our working chase for factory Outlets for s Making Building Material Wall Panel Metal Roofing Corrugated Tile Roll Forming Machine For Sale, Our company insists on innovation to promote the sustainable development of enterprise, and make us become the domestic high-quality suppliers.
To create extra value for customers is our enterprise philosophy; buyer growing is our working chase for Roll Forming Machine, Roll Forming Machine For Sale, s Making Building Material Wall Panel Metal Roofing Corrugated Tile Roll Forming Machine For Sale, Our company insists on the principle of “Quality First, Sustainable Development”, and takes “Honest Business, Mutual Benefits” as our developable goal. All members sincerely thank all old and new customers’ support. We are going to keep working hard and offering you the highest-quality solutions and service.
Parameters of corrugated automatic roof tile machine

1 Main motor power 4kW, 3-phase or as your requests
2 Hydraulic motor power 3kW
3 Hydraulic pressure 10-12MPa
4 Voltage 380V/3-phase/50Hz (or as your requirements)
5 Control system PLC delta inverter
6 Mainframe 300/350mm H-beam or 350mm
7 Backboard thickness 16mm
8 Chain size 1 Inch
9 Feeding material color steel coils
10 Feeding thickness 0.3-0.8mm
11 Feeding width 1000mm
12 Effective width 850mm
13 Productivity 0-15/min
14 Roll station 13 roll steps (according to different design)
15 Roller diameter 70mm (depends on different design)
16 Roller material 45# steel
17 Cutter material Cr12
18 Cr-plating size 0.05mm
19 Overall size 6800*1400*1150mm
20 Total weight 4.8 tons

The above are some of the parameters, more detailed parameters can be obtained by contacting us, some of which can be customized according to customer needs.

Detail of machine:

adf sfg

Packaging Details

1. Machine is covered by plastic film.

2. PLC control box, spare parts and other small parts are packed by wooden carton box.
